What would be equivalent of awsvpc mode of ECS using Nomad

What would be equivalent for Nomad (Docker driver) of the networking mode awsvpc (of ECS) which allows a separate IP address for each task container?

Anyone have a job definition sample which demos this?

My use case (as of now) is “separate IP address per Docker container”

The versions I am currently am on are:
Amazon Linux 2
Consul: 1.10.1
Nomad: 1.1.2
CNI Plugins: 0.9.1

@angrycub @lgfa29

Do let me know, if any other information is required!

1 Like

After a little bit of digging, I got this:

and this …

The binaries of the CNI plugins are inside the ECS Agent Docker image, which I was able to extract:

/tmp/foo/amazon-ecs-cni-plugins
$ file *
aws-appmesh:    ELF 64-bit LSB executable, x86-64, version 1 (SYSV), statically linked, stripped
ecs-bridge:     ELF 64-bit LSB executable, x86-64, version 1 (SYSV), statically linked, stripped
ecs-eni:        ELF 64-bit LSB executable, x86-64, version 1 (SYSV), statically linked, stripped
ecs-ipam:       ELF 64-bit LSB executable, x86-64, version 1 (SYSV), statically linked, stripped
vpc-branch-eni: ELF 64-bit LSB executable, x86-64, version 1 (SYSV), statically linked, stripped

Though the original question remains; can Nomad directly use these (after copying to /opt/cni/ or anything equivalent would also do (something like macvlan, etc…
